Western Red Cedar Wood Roof Shingle Ridge & Hip Cap - 94mm Cover
Description
Western Red Cedar Shingles & Shakes are a truly renewable and sustainable roofing and cladding material; with one of the lowest carbon footprints of any widely used building product. They are light to transport yet durable and offer a high degree of thermal insulation.
Shingles and Shakes have been used for a wide range of structures from simple garden gazebos to domestic dwellings to major theme parks. Shingles and Shakes perform the same functions but are manufactured in different ways. A Shingle is produced by sawing a block of wood on both sides, giving a relatively smooth face and back. A Shake is hand split from a block of cedar along the natural grain of the wood and then resawn to produce one smooth surface.
Can be used for ridges & hips. The premium-grade of shingles for roofs and sidewalls.
It is recommended that ridge caps are installed using four 2.65 x 41mm Stainless Steel Annular Ringshank Nails.
Properties
Length: 450mm.
Width: 8cm per wing.
Coverage: 94mm - 125mm.
Treatment: untreated - clean.
Coverage: 94.4mm per ridge at a 14-21 degree pitch.
125mm per ridge at a 22-89 degree pitch.
Installation
Pre-formed Hips and Ridges. These speed up and simplify installation. These are fixed alternately as the same gauge as the roof.
Specification
Dimensions
Details
Questions & Answers
Question:
MY GAZEBO RIDGE LENGTH IS 2.5m 4 in number ridges. how many ridge tiles do I require
Answer:
I will send you a quote
Question:
I have a ridge 3.8m long. I think the pitch is 24. How many will I need?
Answer:
30 ridges should cover that for you, with each one offer 125mm cover.
Question:
How are these fitted ? All one direction or working in from each gable and meet in the middle ?
Answer:
Best to fix all in one direction running along the roof.
Question:
Hi, I have a horizontal ridge of 1.9m (Playhouse). The roof pitch is 22.5 degrees. Can you advise if these ridge caps are suitable and how many i would need. Regards Brendan
Answer:
These would be suitable and you would need approx 15-16 to cover that length after overlapping them.
Question:
Any nails will be needed for 10.5 of ridge, 84 ridge pieces ?
Answer:
Yes you would need nails for fixing, we advise the below for Cedar Shingles.
https://www.roofingsuperstore.co.uk/product/silicone-bronze-annular-ring-nails-31mm-x-1-8mm-1kg.html
Question:
I have a ridge of 10.5 m, and 20 degree angle. Based on each length at 450 mm, i need 23 by my calculations but on your q and a it stated for 5 m length you need 54 ridge pieces, now I’m confused. Can you help ?
Answer:
They are 450mm long but once overlapped at that pitch they will only over 94mm each so you would need approx 111 ridges.
Question:
I have a ridge length of 5m how many ridges would I need?
Answer:
If the pitch is over 22° you will need 40 ridges.
If the pitch is below 22° you will need 54 ridges.
Question:
What angle are these please?
Answer:
These are set at a 125° angle.
