Providing a weathertight, mortar-free and strong solution for all types of the three main interlocking tiles, including large and medium standard format and large format thin leading edge, as well as the Marley Maxima and Lincoln clay pantiles, this Universal Dry Verge Unit has been designed to deliver a secure method for finishing the verge detail.
Complying with the BS 5534 requirements as a way of mechanically fixing verge tiles, this Dry Verge Unit is simple and quick to install, retaining the stepped look of a traditional mortar-bedded verge. Suitable for roof pitches from 12° up to 55°, tiles must be laid at a minimum of 287mm to a maximum of 345mm in accordance with specific tile gauge parameters. Two starter units are included within each dry verge fixing kit.
Please note:
There are no product downloads to show.
Question:
is the price for just one unit. ie if i need 10 its 10 x £10.88
Answer:
Yes, this is sold as an individual unit, so you would need 10 units for 10 verge positions. Please note the displayed price may change; the current product price should be checked on the product page.
Question:
Hello What is the length of each unit?
Answer:
Each Marley Universal Left Hand Dry Verge Unit - Smooth Grey measures 320mm in length.
Question:
I need to replace around 16No old Marley L/H & R/H VERGE UNITs CODE: 391 and 392 and the cap on the apex. Would these work as a direct replacement of all units? Or is there an alternative I need to get? Thanks
Answer:
The Marley Universal Dry Verge Units could potentially serve as replacements for your old Marley units. They are available in both left-hand and right-hand orientation, in Smooth Brown, Smooth Grey, and Terracotta colours. However, without knowing the exact specifications of your old units, it's difficult to guarantee that these will be a direct replacement. The Marley Universal Dry Verge Units are designed to work with roofs that have a minimum pitch of 12 degrees and a maximum pitch of 55 degrees. They are made from durable polypropylene material. If your old units fall within these specifications, the Marley Universal Dry Verge Units could be a good fit. To be certain, I would recommend checking the specifications of your old units or contacting Marley directly for confirmation. As for the cap on the apex, it would depend on the specific design of your roof. Marley does offer a range of roofing accessories that could potentially fit your needs. I hope this information helps! If you have any further questions, feel free to ask.
Question:
Is this suitable to retrofit over an existing Marley Ludlow concrete tile roof, no barge board Currently concrete along the edge of the tiles Thanks
Answer:
The Marley Universal Left Hand Dry Verge Unit is designed to work with many different types of tiles, including Marley Ludlow concrete tiles. It's a versatile product made from durable polypropylene and it can be installed on a roof pitch between 12 and 55 degrees. However, for a retrofit over an existing roof without a barge board, you might need additional components or a specific installation method. We would recommend checking with a roofing specialist or a builder to ensure proper installation.
Question:
Whats the batten over hang with these dry verge
Answer:
The Marley Universal Right Hand Dry Verge Unit does not specify a particular batten overhang. It's designed to work with a wide range of roof pitches and tiles. However, dry verge manufacturers generally recommend an overhang of between 20mm and 50mm. It's always best to follow the specific guidelines provided by your roofing tile manufacturer to ensure the best fit and performance. If you need more specific information, you may want to contact Marley directly or consult with a roofing professional. You can find more details about this product on its product page.
Question:
Does this have approximate dimensions, 55mm deep, 100mm wide at the overlap end ( with holes) 150mm wide at the end, length of 420mm ??
Answer:
Hi
Question:
Is this product compatible with the 391 discontinued drive verve. I need 1 to replace a broken verge.
Answer:
Im sorry no its not compatible
Question:
What is the width and length of this product?
Answer:
Please have a look at this link
https://www.marley.co.uk/accessories/universal-dry-verge
Question:
Do these work with the Marley Mendip tiles?
Answer:
Yes, this would work with the mendip
Question:
Do they fit 20/20 inter locking tile 15 degree pitch.with the 100mm overlap.ðŸ‘
Answer:
No, they are from two different suppliers
Question:
How many come in a pack?
Answer:
They are sold individually
Question:
Would this product be the same as Marley Eternit L/H Verge Unit - grey?
Answer:
Hi Glen
You would need to check with Marley as the "Eternit" range is no longer in production.
