Redland DuoPlain Concrete Interlocking Roof Tile Smooth - Tuscan Red

Product Code:
6101/11
Brand:
Est. Delivery: 7-10 Working Days
View Transport Policy

All delivery charges are included in the final shopping basket and are dependent on the products Scottish Highlands & the Islands where additional shipping charges will apply.

Please note that not all products will incur an additional delivery charge to the Scottish Highlands & the Islands – this is based on the costs from the manufacturer, distributor or courier providing shipping on our behalf. If your delivery address is in the Scottish Highlandsand Islands, a member of our helpline team will contact you prior to processing your order should an additional delivery charge apply.

While we make every effort to ensure orders are delivered by the date required, we cannot guarantee availability from the manufacturer or the manufacturer's delivery schedules.

Any variation to web delivery date given will be advised to you by email or telephone. If we are unable to make delivery because access is not possible, we reserve the right to make a failed delivery charge.

£1.33 Incl. VAT
£1.11 Ex. VAT
Oops! Please select from the options

Product Description

DuoPlain combines the classic proportions and good looks of traditional plain tiles with all the time and cost-saving benefits of a modern, large-format interlocking tile.

Engineered for strength, ease of handling and ease of installation, it fulfils the three main demands of a modern roofing site. Now available in seven popular colours with the addition of our brand new Blue, DuoPlain also comes with a full range of matching fittings and accessories.

Properties

Size: 268mm x 330mm.
Minimum pitch: 25°.
Maximum pitch: 90° - subject to fixing specification.
Minimum headlap: 80mm.
95mm.
Maximum headlap: 173mm.
Minimum gauge: 188mm.
Tile thickness: 17mm.
Coverage: 17.7 tiles/m2 at maximum gauge.
Weight: 3.1 tonnes/1000.
Batten size: 38mm x 25mm - rafter centres up to 450mm.
50mm x 25mm - rafter centres up to 600mm.
Battens required: 5.26m/m2.
Nail size: 40mm x 3mm - aluminium alloy.
45mm x 3.35mm - stainless steel ring shank.
38mm x 4.2mm - stainless steel screws.
Tile finish: through coloured & acrylic coated.

BBA certified.
DuoPlain Tiles conform to BS EN 490: 2004 Concrete roofing tiles and fittings for roof covering and wall cladding - Product Specifications.

Details

Size 268mm x 330mm Type Tile Finish Smooth Colour Tuscan Red Material Concrete
Profile DuoPlain Minimum Pitch 25 Degrees
