Samac Countersunk Atlas Bolts ZYP M6 x 50mm - Box of 100

Product Code:
XAB650CSK
Est. Delivery: 1-2 Working Days
Shipping costs displayed in basket.
We can let you know when this product is back in stock.

This product is proving to be very popular and has unfortunately sold out.

Enter your email below and we'll notify you as soon as this product is back in stock:

Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.

View Transport Policy

All delivery charges are included in the final shopping basket and are dependent on the products Scottish Highlands & the Islands where additional shipping charges will apply.

Please note that not all products will incur an additional delivery charge to the Scottish Highlands & the Islands – this is based on the costs from the manufacturer, distributor or courier providing shipping on our behalf. If your delivery address is in the Scottish Highlands and Islands, a member of our helpline team will contact you prior to processing your order should an additional delivery charge apply.

While we make every effort to ensure orders are delivered by the date required, we cannot guarantee availability from the manufacturer or the manufacturer's delivery schedules.

Any variation to web delivery date given will be advised to you by email or telephone. If we are unable to make delivery because access is not possible, we reserve the right to make a failed delivery charge.

£15.73 Incl. VAT
Oops! Please select from the options

Product Description

Samac Countersunk Atlas Bolts ZYP M6 x 50mm - Box of 100

Manufactured from high tensile boron steel, and with 10 sharp thread forming teeth, the Atlas Bolt ensures fast and simple installation when used on a wide range of substrates. Suitable substrates include, concrete, concrete block, brick, timber, stone and marble.

Atlas Bolts have a dual thread which ensures correct alignment when fitting, and can be completely removed.

Dimensions
Size: 6mm x 50mm
Head Type: Countersunk
Head Size: T-30 Bit
Drill Size: 6mm
Maximum Fixture Thickness: 20mm


Benefits

Manufactured from high tensile boron steel.
Fast and simple installation.
Fully removable.
High loads with low expansion forces - an effective alternative to chemical anchors.
Suitable for close to edge fixing.
10 sharp thread forming teeth.
Available with 3 different screw heads: Countersunk, Hex Flange and Hex.
Dual thread ensures correct alignment.
Suitable for a wide range of substrates; from timber to marble.
Tensile strength of 800N/mm2 after heat treatment.

Please note, to achieve the published tension and shear loads, Atlas Bolts should be installed at least 10x the anchor diameter between each bolt and 10x the anchor diameter from the edge of the base material.

If spacing or edge distance is reduced, users should apply the appropriate reduction multiplier to the published load to ascertain the correct load. For more technical data, please see the attached Data Sheet.
