Suited to a minimum roof pitch of 22.5?, this 418mm x 335mm Sandtoft New Rivius Interlocking Clay Roof Tile is an alternative to traditional slate. Unlike slate, which demands time, complexity, and expense to install, the Rivius is a large format, convenient and cost-effective...Read More
Suited to a minimum roof pitch of 22.5?, this 418mm x 335mm Sandtoft New Rivius Interlocking Clay Roof Tile is an alternative to traditional slate. Unlike slate, which demands time, complexity, and expense to install, the Rivius is a large format, convenient and cost-effective solution. The interlocking clay tile eliminates the need for double lapping, thanks to its design.
A practical and affordable choice for various projects, including self-build and social housing projects where the appearance of slate is desired but unattainable, the Rivius is crafted with precision using bespoke moulds from imprints of Welsh slate. This provides the intricate details and authentic texture of natural slate.
As part of the New Generation portfolio, the Rivius Slate embraces an interlocking format known for its easy installation. An open gauge product that maintains an authentic slate appearance, approximately 50% more cost-effective than natural slate, it is also 10% larger and 10% lighter with a colour that remains unfading.
Providing a coverage of 9.5 tiles per m², this tile suits a minimum headlap of 75mm and a maximum of 120mm, with batten spacing of 298mm to 343mm.
Question:
At the min pitch of 22.5 degrees what is the required headlap?
Answer:
100mm
Question:
How many tiles per square metre?
Answer:
Tile Coverage per m²: 9.5 tiles per m².
Question:
what is the thickness of this tile?
Answer:
These tiles are 16mm thick.
