With various finish, glazing and operation options to choose from, this VELUX GGL MK04 centre-pivot roof window features innovative Thermo-Technology™ which transfers minimal energy so your home can stay warm and comfortable. Ideal for transforming your small room with plenty ... Read More
SUPER rewards Earn points and save £££ on our SUPERSTORES
Find out more
Pay in 3 interest-free payments of £0.00
Learn more
With various finish, glazing and operation options to choose from, this VELUX GGL MK04 centre-pivot roof window features innovative Thermo-Technology™ which transfers minimal energy so your home can stay warm and comfortable. Ideal for transforming your small room with plenty of daylight, it includes click-on covers which ensure a speedy, easy and safe installation.
With a straightforward red and blue line bracket system, you can distinguish between standard and recessed installations. Providing seamless movement thanks to the high-quality pivot hinges, this VELUX centre-pivot window effortlessly rotates 180° and secures into place with a built-in barrel bolt so you can clean the outer pane from the safety of inside your home. With a convenient yet elegant top control bar, you can allow fresh air to flow into your home through the ventilation flap even when the window is closed while the filter stops insects and dust.
Including pre-mounted brackets, you can find the perfect interior blind to complement your colour scheme and fit your window so you can control the amount of daylight that enters your room. It simply clicks into position, and you can insert the pre-cut side channels.
What’s more, all the standard glazing options boast quality features including a UV filter, VELUX’s unique rain noise reduction, safety lamination and toughened glass. The rain noise reduction helps to ensure a peaceful night’s sleep without heavy rain noise on the window while the UV filter safeguards your furnishings against harmful UV rays which can cause fading. The toughened glass offers extra strength to the outer pane to protect against external environmental factors while the safety lamination inhibits the glass from falling if it were to accidentally break.
There are no product downloads to show.
Question:
what is the correct flashing kit for 13/3 corrugated plastisol sheeting
Answer:
The correct flashing kit depends on the roof profile and pitch. This window is suitable for roof pitches from 15° to 90°, but the information provided doesn’t confirm which flashing kit suits 13/3 corrugated plastisol sheeting. Please check with our technical team or the supplier to confirm the compatible kit before ordering.
Question:
VELUX GGL MK04 207021U White Centre Pivot Electric Window INTEGRA - 78cm x 98cm - is this window anthracite colour on the outside please?
Answer:
Yes, the VELUX GGL MK04 207021U White Centre Pivot Electric INTEGRA window has a grey powder-coated aluminium external cladding, which is the standard VELUX external finish and is generally described as anthracite grey/dark grey in appearance from the outside. The "White" in the product name refers to the internal white-painted timber finish, not the exterior. So in summary: - Inside: White-painted timber finish - Outside: Grey powder-coated aluminium cladding (dark grey/anthracite appearance) If you're trying to match existing anthracite windows or rooflights, this VELUX finish is typically a good visual match, although it is not supplied in a RAL 7016 anthracite powder coat as standard.
Question:
VELUX GGL MK04 2070 - IS this UPVC or painted wood
Answer:
The VELUX GGL MK04 2070 White Centre Pivot Window is made from high quality natural pine that has been painted white. It's not made from UPVC. The protective triple coat clear lacquer helps preserve the timber of the window.
Question:
Just a silly simple question dose the window come with flashing kits
Answer:
The VELUX GGL MK04 2070 White Centre Pivot Window does not come with a flashing kit included. Flashing kits are typically purchased separately as they need to be chosen based on the type of roofing material you have. VELUX offers a variety of flashing kits compatible with various roofing materials. It's advisable to purchase a flashing kit that corresponds with your specific roofing material for optimal installation.
Question:
What is the minimum roof pitch this is compatible with?
Answer:
The VELUX GGL MK04 2070 White Centre Pivot Window can be installed on roofs with a minimum pitch of 15 degrees.
Question:
is the outside of this window anthracite and inside white
Answer:
The VELUX GGL MK04 2070 White Centre Pivot Window Laminated - 78cm x 98cm has a white painted finish on the inside. The exterior design has an improved finish and Anthracite on the outside
Question:
Does the unit have wiring pre installed for electrically operated blinds?
Answer:
The VELUX GGL MK04 Centre Pivot Roof Window does not come with wiring pre-installed for electric blinds. However, we do offer versions of this window that have electric operations, such as the VELUX GGL MK04 206621U Centre Pivot INTEGRA Electric Window and the VELUX GGL MK04 307021U Pine Centre Pivot INTEGRA Electric Window. These models are designed for use with electric blinds and would have the necessary wiring. Please note that the blinds would need to be purchased separately. If you have further questions or need assistance with the installation process, our customer service team would be more than happy to help.
Question:
When the window is closed is there any ventilation?
Answer:
Yes, the VELUX GGL MK04 2070 White Centre Pivot Window does provide ventilation even when it's closed. It has an innovative top control bar that allows for both opening the window and for ventilation purposes when the window is closed. This ensures a constant flow of fresh air, helping to maintain a comfortable indoor environment. You can find more details about its operation in the fitting instructions located here.
Question:
Is it 98cms tall and 78cms wide or the other way around?
Answer:
The VELUX GGL MK04 307021U Pine Centre Pivot INTEGRA Electric Window measures 78cm in width and 98cm in height. For more details, feel free to visit the product page here.
Question:
I have already got a Velux MK04 2070 from Velux themselves. If I buy this one from you will it match exactly? They will both be in the same room.
Answer:
Yes, the VELUX GGL MK04 2070 White Centre Pivot Window Laminated that we sell is the same as that sold by VELUX themselves. It has the same dimensions of 78cm x 98cm and features a white painted finish with manual operation. As long as the model numbers are the same (GGL MK04 2070), you can expect the two windows to match exactly.
Question:
Is the electric opening control included with the window and how is it operated?
Answer:
Yes, the VELUX GGL MK04 307021U Pine Centre Pivot INTEGRA Electric Window comes with an integrated electric operation. This allows you to easily open and close the window using a control bar. Aside from that, it also has built-in rain sensors that automatically close the window when it detects rain. This feature is particularly useful for hard-to-reach windows. It is easy to install and only requires plugging into a power supply. You can find more details on how to operate and install this in the product's Installation Guide which you can access here: VELUX INTEGRA Installation Guide
Question:
What does the guarantee cover, please? Mine is broken at the handle.
Answer:
The guarantee provided by VELUX typically covers issues arising due to manufacturing defects. However, it's important to note that it usually does not cover accidental damage or issues due to normal wear and tear, which might include a broken handle. To get the most accurate information on what your guarantee covers, I'd recommend referring to the original documentation that came with your VELUX GGL MK04 2070 White Centre Pivot Window. If you have misplaced this, our customer service team might be able to assist further or you may want to contact VELUX directly for clarification.
Question:
My ggl c04 electric windows work fine but the windows themselves have started to leak - they’re pitched at about 15degs. Do you sell just the replacement window (i.e. without the surround) compatible with electric opening mechanism? Thanks
Answer:
I'm sorry, but we do not sell the windowpane separately for the VELUX GGL MK04 3070 Pine Centre Pivot Window Laminated - 78cm x 98cm. We only sell the complete unit as they come supplied from VELUX assembled. If your window is leaking, it might be worth looking at how the flashing has been installed - if this is not correctly installed it can lead to leaking. You can refer to the VELUX Installation Guide for more details on proper installation. Here's the link to the guide: VELUX Installation Guide. If you continue to have issues, it may be best to contact a professional for an assessment.
Question:
What is the aperture size required for this window? Do you have a pdf drawing of the window. I only have 100cm on the length between horizontal trusses. I'm sure I read that the sizes 78 x 98cm was the outside size of the window but a message in this thread says it is plus 45mm on the 98cm length. Does the window come with a tile flashing or is that an extra?
Answer:
The dimensions of the VELUX GGL MK04 Centre Pivot Roof Window are indeed 78cm x 98cm. However, this refers to the external frame size. The actual structural opening required for installation will be slightly larger, generally about 20mm more around each side, so you would need to account for this when fitting the window. You can find more detailed dimensions and technical drawings in the downloads section of the product page. Regarding your question about tile flashing, it is not included in the package and needs to be purchased separately. You can find a suitable flashing kit on our website in the 'Pitched Roof Windows' category, or in the ancillaries on the right of this product page. Please ensure you select a flashing kit that is compatible with your specific roof material and profile.
Question:
Hi, please could you tell me if this product Will fit with original flashings ( if in good condition) with the already installed GGL 304 3000? Thanks
Answer:
I'm sorry, but the VELUX GGL MK04 2070 White Centre Pivot Window Laminated - 78cm x 98cm is not compatible with the original flashings of the GGL 304 3000. VELUX flashings are not compatible across different generations. It's recommended to use the appropriate flashings with the window model for a proper fit and to ensure the window functions correctly. You might need to purchase new flashings suitable for this specific model. If you need further assistance, please contact our sales team or use the search function on our website to find the correct product.
Question:
Hi. Do both solar and electric versions have rain detection to close windows automatically?
Answer:
Yes, both the solar and electric versions of the VELUX GGL MK04 Centre Pivot Roof Window have an automated rain sensor feature. This enables the window to close automatically when it detects rain, ensuring your interior remains dry and protected.
Question:
What is the lowest pitch of roof this window can be fitted to.
Answer:
The lowest pitch this window can be installed is 15 degrees.
Question:
Could you please give the dimension for the opening light ( ie lining to liniing)
Answer:
Pane size is 629 x 836 and the glass is 590 x 778
Question:
Is the GGL MK04 2070 a direct replacement for an old GGL 304 3000 please?
Answer:
Yes that is a direct replacement
Question:
what is the solar operation velux window
Answer:
It will work the same as an electric window and comes with a remote control
Question:
Do you provide site visits to measure up and quote? The property is in Rye East Sussex.
Answer:
Im sorry no we dont offer that service
Question:
Are the black out blinds inside the windows or separate to the windows when delivered?
Answer:
The blinds are a separate unit and can be installed after the windows
Question:
Hello, what is the opening size for the MK04 78x98cm model? Thank you
Answer:
The structural opening size would be an extra 40-60mm on the 78cm and 45mm+ on the 98cm
Question:
Hi, I'm looking to fit an old GGU 304 window on a pan-tile roof @ 45 degrees. Does the EDW MK04 0000 flashing kit work with the older style window or will I need to purchase a new window and EDW MK04 0000 flashing kit?
Answer:
No this will not work. I will email you a quote
Question:
Is this suitable for means of escape ?
Answer:
You would need to check your local building reg's also a top opening window would be better
Question:
Does the window have a open locking system. Would I receive a discount if I placed an order for 4.
Answer:
Yes, the window will lock when opened.
Question:
I’m after 4 of these windows. I’m not sure of the flashing kit I require for my job. They are similar to a Marley Ludlow tile. . And what is the availability of the windows Thanks
Answer:
I have sent you a quote with the correct flashing
Question:
Would the pivot velux work on a 15% gradient roof ?
Answer:
The windows are tested down to 15dg so yes it will open
Question:
My mother has had mk04 windows fitted on a pitched roof extension… is there a minimum pitch for this kind of window? Building regs situation
Answer:
It depends on the Velux window type - if its a GGL they are only tested down to 15dg - if its a GBL then its as low as 10dg on a tiled roof
Question:
I have three Velux GGL MK04 fitted in a room and en suite bathroom. One locks with the handle easily, the other two do not. What am I doing wrong? I have set the two levers in the same position as the one that works, but they wont go all the way home. Frank Jackson
Answer:
The best think would be to call Velux technical about this - they are really helpful 01592778225
Question:
What type and size screws are used for the outside cladding on the GGL-4 roof window? My cladding came partially off due to an error in replacing the glass and some screws were lost. Thank you for your help.
Answer:
It would be better for you to call Velux on this one I'm afraid 01592 778228
Question:
Hi, does the electric VELUX window needs a different type of flashing because it's electric compare to simple ones please.Or just depends on the type of tiles, thank you
Answer:
There are different types of flashing I will email you a quote.
Question:
Does it come with flashing kit
Answer:
No You will need to order one
Question:
Hi there, looking for this size window for a bathroom so require obscured glass. Is there an option for this please regards john
Answer:
Hi John
You can no longer buy obscured glass. You could buy the film yourself and add it or you could buy a blind. I have sent you a quote please check the flashing is correct. If you need anymore help give us a call
Question:
Any discount for ten
Answer:
Good Morning Les
I am working on a better price for you and will send you a quote
Question:
Your quotation for three Velux windows , manual ,external black colour , opening from bottom , ventilation siz 780 mmx 980mm , U-value 1.3 or less
Answer:
Hi Foad
I will send you a personal email with a quote
Question:
Hi What colour is the outside of this product? Thanks
Answer:
Hi Emma
Dark grey
Question:
Hi. What flashing kit should I order for the Velux GGLMk04 when installed on a pitched roof using Cedar shingles please?
Answer:
Hi Simon
you would need the EDW flashing and you would have to remove some of the insulation off the back of the flashing in order to get it to sit correctly
Question:
what is the flashing code for slate?
Answer:
For slate you would need product code EDL MK04 0000.
If doing a recessed Slate installation you would need EDN MK04 0000.
Question:
What flashing is required for a 78cm x 98cm Velux rooflight? The roof is large concrete tiles.
Answer:
For a large concrete interlocking or profiled tile you would need the below EDW Flashing kit.
https://www.roofingsuperstore.co.uk/product/velux-edw-mk04-0000-single-120mm-tile-flashing-78cm-x-98cm.html
